Fly Ash/Sand & Slurry Hose
Application:
Fly Ash Rubber Hose, tank, truck, Bulker loading / unloading or in-plant transfer of dry bulk cement, sand, lime, slurry etc., suction or discharge of abrasive materials.
Construction:
Lining : Uniform seamless tube of natural and synthetic blend rubber compound with excellent resistance to abrasion.
Reinforcement : Reinforcement of rubber impregnated woven textile applied on bias at approx.45 degree angle combination with galvanized steel wire
Cover : Corrugated/plain cloth marked outer cover made from natural rubber compound with excellent weather and abrasion resistant.
End Connections : Each Hose Length has soft ends for clamping or can be supplied with different type of nipples, flanges or fittings as per requirement.
Cover: W.P. of 1.0 Mpa & Min. B.P. of 3.0Mpa.
W.P. of 1.5 Mpa & Min. B.P. of 4.5Mpa .
-
S.No Description Max Length 1 3” (75mm)ID x 5Mtr (LG) with Both End MS Flange as per ASA 150# 15 Mtr 2 4” (100mm)ID x 5Mtr (LG) with Both End MS Flange as per ASA 150# 15 Mtr 3 5” (125mm)ID x 5Mtr (LG) with Both End MS Flange as per ASA 150# 15 Mtr 4 6” (150mm)ID x 5Mtr (LG) with Both End MS Flange as per ASA 150# 15 Mtr
